4-ch Current and Power Monitor HAT for Raspberry Pi
A versatile HAT for monitoring current, voltage, and power consumption on your Raspberry Pi.
- Channels: 4
- Interface: I2C or SM Bus
- Sampling Resistor: 0.1?
- Max Current: 3.2A
- ADC: 12-bit
- Voltage Range: 0~26V
Features:
- Standard Raspberry Pi 40PIN GPIO extension header
- 4-ch monitoring via I2C/SM Bus interface
- Supports bidirectional current measurement
- Embedded ADC for accurate readings
This 4-ch current and power monitor HAT is designed for Raspberry Pi, allowing you to easily monitor current, voltage, and power consumption on each channel. The module supports bidirectional current measurement, making it versatile for various applications.
Each channel (IN1+ IN1-, IN2+ IN2-, IN3+ IN3-, and IN4+ IN4-) can be tested for currents and voltages. By measuring the differential voltage of the sample resistor connected between the input and output, the module accurately calculates the working current.
The package includes 1 Current/Power Monitor HAT, 1 2x20PIN female pin header, and 1 RPi screws pack (2pcs). Additionally, it comes with development resources and a manual with examples for Raspberry Pi, Arduino, and STM32.
