TE CONNECTIVITY FS-10 Vertical Flow Switch
Reliable vertical flow switch for water and air flow switching
- Maximum Switching Volts: 300 VDC
- Maximum Switching Current: 1.0A
- Maximum Watts: 15 Watts
- Mounting: Flow Switch Vertical
- Material: Copper
- Fitting: Flow Switch 15mm pipe size
- Contact Form: Form A - SPST
- Contact Material: Ruthenium
- Cable Type: 2 x 16/0.2mm PVC insulated 1.0M long
- Cable Colour: Black/Black
- Operating Temperature Range: 85°C
- Medium/Liquid: Water
- Flow Rate: 0.5 litres/min
- Operating Pressure: 10BAR
- Mounting Shock: 50g for 11ms duration
- Mounting Vibration: 35g up to 500Hz
Features:
- 15mm copper pipe
- Minimal pressure drop
- Operates from a small head of water
- Vertical mount 15
The TE CONNECTIVITY FS-10 Vertical Flow Switch is designed for easy installation and offers reed switch reliability. It is suitable for various applications including mains water control, power showers, central heating systems, leak detection, and cooling systems.
Package Includes: 1 x TE CONNECTIVITY Flow Switch, FS-10
