STM32F103CBT6 Minimum System STM32 ARM Core Board
A low-cost Minimum System Development Board for ARM Microcontroller STM32F103CBT6
- Model: STM32F103CBT6
- Clock Speed: 72MHz
- Memory: 128KB Flash, 20KB SRAM
- GPIO: 34
- Operating Voltage (VDC): 3.3
- Length (mm): 52
- Width (mm): 17
- Height (mm): 5
- Weight (gm): 7
Features:
- 72MHz work frequency
- 128KB flash memory, 20KB SRAM
- 34 digital I/O pins (GPIOs)
- 12 PWM pins at 16-bit resolution
This board is suitable for learners who want to explore the STM32 microcontroller with ARM Cortex-M3 32-bit core.
Package Includes:
- 1 x STM32F103CBT6 Maple Mini STM32 ARM Core Development Board
Images are for illustration only; actual product may vary.
