SO/MSOP/TSSOP/SOIC/SOP8 to DIP8 PCB Transfer Board
A convenient solution for prototyping with different IC packages
- Dimensions: 12 x 12 mm
- Pitch: 0.4 mm
Features:
- Double-Side PCB Circuit Board
- Compatible with 4 pins, 6 pins, and 8 pins chips
- 1.27mm pin pitch size for SO, SOP, SOIC to 2.54mm DIP
- 0.65mm pin pitch size for SSOP, TSSOP, MSOP to 2.54mm DIP
SO/MSOP/TSSOP/SOIC/SOP8 packages are commonly used in Opamps and Memory ICs for low space, high functioning environments. When prototyping with microcontroller ICs in DIP packages, connecting components with jumper wires and breadboards is necessary. This PCB Transfer Board simplifies prototyping by allowing easy conversion from SO/MSOP/TSSOP/SOIC/SOP8 to DIP package, eliminating the need for soldering and de-soldering. It accommodates both 1.27mm and 0.65mm pin spacings for various IC packages, making rapid circuit design and testing hassle-free.
Simply solder the IC onto the board and connect the DIP pins using a breadboard or jumper wires. The board features two sides for different pin spacings, ensuring compatibility with a wide range of IC packages. This cost-effective solution is ideal for prototyping projects that require quick iterations and component testing.
Images are for illustration only; actual product may vary.
