RP LIDAR A2M12 360 degrees Laser Range Finder-12 Meter Range
The next-generation low-cost 360 degrees 2D laser scanner solution with high rotation speed.
- Range: 12 meters
- Scanning Frequency: 10Hz (600rpm)
- Resolution: 0.225
- Sample Rate: 16000 samples per second
- Technology: SLAMTEC patented OPTMAG
- Environment: Indoor and outdoor without direct sunlight exposure
- Power: 5V DC
- Interface: XH2.54-5P male socket
Top Features:
- 360-degree laser range scanning
- 16000 times sample rate
- 12m range radius
- Low noise, brushless motor
The RPLIDAR A2 is an enhanced version of the 2D laser range scanner, capable of 2D 360-degree scans within a 12-meter range. It is suitable for mapping, localization, and object/environment modeling. The system utilizes laser triangulation measurement technology for accurate performance in various environments.
The RPLIDAR A2 operates by emitting modulated infrared laser signals and processing the returning signals to determine distance and angle values. It is ideal for applications such as robot navigation, 3D modeling, and obstacle avoidance.
Package Includes:
- 1 x RP LIDAR A2M12 360 degrees Laser Range Finder (PWM motor driver embedded)
- 1 x USB Cable
- 1 x DC Cable
- 1 x Adapter Driver Board
Need more details or interested in bulk pricing? Reach out to our sales team directly - sales02@thansiv.com +91-8095406416
Images are for illustration only; actual product may vary.
