MEAN WELL Enclosed Type Quad 4 Output Power Supply RQ-85C
Reliable enclosed power supply with 3 years warranty and 87.5W output power
- Output Voltage-Channel 1: 5 VDC
- Output Voltage-Channel 2: 15 VDC
- Output Voltage-Channel 3: -15 VDC
- Output Current-Channel 1: 7A
- Output Current-Channel 2: 3A
- Output Current-Channel 3: 0.5A
- Number of Outputs: 3
- Output Power: 87.5 W
- Type: Enclosed Type Quad 4 Output
- Features: Standard Series RQ (Reliable)
- Mechanical Form: Enclosed
- Warranty: 3 Years Warranty
- IP Level: Non-Waterproof
- Input Voltage: 88 VAC to 264 VAC, 125 VDC to 373 VDC
Top Features:
- Universal AC input / Full range
- Protections: Short circuit / Overload / Over voltage
- Cooling by free air convection
- LED indicator for power on
The MEAN WELL RQ-85C is an enclosed power supply with an output power of 87.5W and a reliable design. It features three output channels with different voltage and current ratings. The unit comes with a 3-year warranty and operates within a wide input voltage range of 88 VAC to 264 VAC. With various protections and high efficiency, this power supply ensures long-term reliability.
Specifications:
- Manufacturer: MEAN WELL
- Output Voltage-Channel 1: 5 VDC
- Output Voltage-Channel 2: 15 VDC
- Output Voltage-Channel 3: -15 VDC
- Number of Outputs: 3 Output
- Output Power: 87.5 W
- Open Frame/Enclosed: Enclosed
- Input Voltage: 88 VAC to 264 VAC, 125 VDC to 373 VDC
- Input Current: 1.5A/230VAC, 2.5A/115VAC
- Output Current-Channel 1: 7 A
- Output Current-Channel 2: 3 A
- Output Current-Channel 3: 0.5 A
- Operating Temperature: -25 TO +70 DEG CEL
- Voltage Adjustable Range: 4.75 ~ 5.5V
- Frequency: 47 TO 63Hz
- Protection: Short circuit / Overload / Over voltage
- Industry: Commercial
- Mounting Style: Chassis
- Length: 159 mm
- Width: 97 mm
- Height: 38 mm
- Safety Standards: UL62368-1, TUV EN62368-1 approved
- Series: RQ-85
- Model: RQ-85C
- Brand: MEAN WELL
- EMC Emission: Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3, EAC TP TC 02
- Unit Weight: 600 g
