PIC Development Board for Microchip PIC Series
Prototype with any 40 pin PIC microcontrollers with RS232 driver
- Compatible with: 16FXXX, 18FXXX (e.g., 16F877A - 40 pin)
- ICSP Socket: For easy programming through PICKIT2
- Regulated Power: Optional 5v, 12v supplies
- Connectivity: RS232 Serial Port, DC Power Supply Connector
- Components: 7Seg Display, LCD 2x16, 24Cxx I2C EEPROM, RTC DS1307
Top Features:
- ICSP Socket for easy programming
- Regulated power supply options
- RS232 Serial Port for PC connection
- On-board components for testing and development
The PIC Development Board for Microchip PIC Series allows you to develop and prototype with any of Microchip's 40 pin PIC microcontrollers. The on-board RS232 driver facilitates easy connection with a PC or other embedded hardware. Additionally, the board features user buttons and status LEDs for convenient operation.
The bridge rectifier on the board enables it to be powered with both AC and DC power supply adapters, offering flexibility in power options. With features like ICSP Socket for programming through PICKIT2 and on-board regulated power supply options, this board provides a user-friendly experience for testing and development.
Easy chip removal is possible with the ZIP Socket, making testing more efficient. The board also includes connectivity options such as an RS232 Serial Port and a DC Power Supply Connector, catering to various connection needs.
Components like the 7Seg Multiplexed Display, LCD display 2x16 Character, 24Cxx I2C EEPROM, and RTC DS1307 enhance the functionality of the board for diverse applications. The inclusion of a 4 LED array, 4x4 Matrix Key Pad, and ULN2003 for driving relays and stepper motors further expands the capabilities of this development board.
Example programs for LED, 7seg, LCD, RS232, Matrix Key Pad, and ADC are provided, offering a head start in utilizing the board for different projects.
*Images are for illustration only; actual product may vary.
