Nextion Intelligent Series HMI Display
A powerful Human Machine Interface solution with advanced features
- Model: NX1060P101-011C-I (HMI Capacitive Touch Display)
- Size (inch): 10.1
- Pixels: 1024*600
- Touch Panel: Capacitive (CTP)
- Flash (MB): 128
- RAM (KB): 512
- MCU (MHz): 200
- GPIOs: 8
- Color: 65536
- EEPROM (Byte): 1024
- RTC: Yes
- Length (mm): 258
- Width (mm): 152
- Height (mm): 11.5
- Weight (g): 720
Top Features:
- Capacitive 10.1-inch touch display
- 200MHz MCU with up to 128MB for projects
- Audio interface and CE/RoHS compliant
- Easy development with Nextion Editor software
Nextion Intelligent Series HMI Display is a comprehensive solution for creating interactive GUI projects. It features an onboard MCU running at 200MHz, ample memory for projects, and a capacitive touch panel for smooth interactions. With 8 GPIOs and a variety of software features, this display offers advanced capabilities for your projects.
The Intelligent Series products boast enhanced hardware specifications compared to Basic and Enhanced Series. With added audio, video, and animation play functions, users can elevate their project's HMI interaction. The support for advanced software features like transparent components and page loading effects further enhances the user experience.
Developing HMI GUI projects is made easy with the free Nextion Editor software version 0.58 or above. By utilizing drag-and-drop components and simple ASCII text-based instructions, the workload for HMI project development is significantly reduced.
Package Includes:
- 1 x NX1060P101-011C-I HMI Display
- 1 x XH2.54 4P Wire
- 1 x Power Supply Test Board
Need more details or interested in bulk pricing? Reach out to our sales team directly - sales02@thansiv.com +91-8095406416
Images are for illustration only; actual product may vary.
