CH340 USB Bus Adapter
A versatile USB bus adapter with serial, parallel, and IrDA interfaces
- Full-speed USB interface: Compatible with USB 2.0
- External components: Requires a crystal and minimum of four capacitors
- Virtual serial port: Upgrade existing devices or add serial ports
- Hardware interface: Full-duplex with internal FIFO
The CH340 is a series of USB bus adapters that offer serial, parallel, or IrDA interfaces over the USB bus. The CH340G variant specifically supports the serial interface. It integrates common MODEM signals to enable adding a UART to a computer or converting existing UART devices to a USB interface.
It supports a baud rate range from 50bps to 2Mbps and common flow control signals like RTS, DTR, DCD, RI, DSR, and CTS. The CH340 uses the CH341 driver and supports RS232, RS422, and RS485 with external level shifting components. It operates at both 5V and 3.3V and comes in a RoHS-compliant narrow body SO-16 package.
- Operating Temperature: -40 to 85°C
- Storage Temperature: -40 to 125°C
- Supply Rail Voltage: -0.5 to 6.5V
- IO Pin Voltage: -0.5 to (VCC+0.5)V
Need more details or interested in bulk pricing? Reach out to our sales team directly - sales02@thansiv.com
+91-8095406416
Images are for illustration only; actual product may vary.
