CC Debugger
A small programmer and debugger for TI Low Power RF System-on-Chips
- Minimum Target Voltage: 1.2V
- Maximum Target Voltage: 3.6V
- Operating Temperature: 0C to 85C
- Regulated Voltage on CC Debugger: 3.3V
- Maximum Target Current: 200mA
- Supported Operating Systems: Windows 7, Windows 8, Windows XP SP2/SP3, Windows 2000
- Length (mm): 40
- Width (mm): 60
- Height (mm): 15
- Weight (gm): 25
Features:
- Program and debug 8051-based system-on-chips
- Control devices from SmartRF Studio
- Program PurePath Wireless devices
The CC Debugger is a small programmer and debugger designed for the TI Low Power RF System-on-Chips. It is compatible with IAR Embedded Workbench for 8051 (version 7.51A or later) for debugging and SmartRF Flash Programmer for flash programming. Additionally, it can control selected devices from SmartRF Studio.
Package Includes:
- 1 x CC Debugger
- 1 x USB cable
- 1 x 10Pins flat cable
*Images are for illustration only; actual product may vary.
