Autonics CR30-15DP DC 10-30V 15mm M30 Capacitive Proximity Sensor PNP-NO (Unshielded)
Enhance superior noise resistance characteristics with dedicated IC for various applications.
- Model: Autonics CR30-15DP PNP-NO
- Operating Voltage (VDC): 10 ~ 30
- Detection Distance (mm): 15
- Outer Thread Size: M30
- Object Type: Capacitive
- Output Type: PNP Normally Open Three-line
- Installation Type: Non-Flush (Unshielded)
- Max Output Current (mA): 200
Features:
- Detect various materials including metal, iron, stone, plastic, water, and grain.
- Long life cycle and reliable performance.
- Built-in surge protection circuit, reverse polarity protection circuit (DC types).
- Built-in surge protection circuit (AC types).
Capacitive proximity sensors can detect metallic and non-metallic targets like paper, wood, plastic, glass, powder, and liquid without physical contact. The sensor works on the capacitor principle where the capacitance increases as the object comes close to the plate. The detector circuit switches the output based on the amplitude output from the oscillator.
Advantages: It can detect both metallic and non-metallic targets, good stability, high speed, good resolution, low power usage, and cost-effective.
Package Includes: 1 x Autonics CR30-15DP DC 10-30V 15mm M30 Capacitive Proximity Sensor PNP-NO (Unshielded).
Specifications:
- Setting Distance (mm): 0 ~ 10.5
- Insulation Resistance (M): 50
- Operating Temperature (C): -25 to 70
- Storage condition: -30 to 80C
- Cable Dimensions: 5, 3-Wire, 2 Meter
- Response Frequency: 50Hz
- Weight (gm): 180
- Shipment Weight: 0.25 kg
- Shipment Dimensions: 11 x 7 x 9 cm
* Images are for illustration only; actual product may vary.
