74LS273 Octal D-type Flip-Flop with Reset IC (74273)
Monolithic flip-flops with TTL circuitry for D-type logic and direct clear input.
- Supply Voltage: 4.75 - 5.25V
- High-level output current: -800µA
- Low-level output current: 16mA
- Clock frequency: 30MHz
- Width of clock or clear pulse: 16.5ns
- Package Includes: 1 X 74LS273 Octal D-type Flip-Flop with Reset IC (74273) DIP-20 Package
Top Features:
- Contains Eight Flip-Flops With Single-Rail Outputs
- Buffered Clock and Direct Clear Inputs
- Individual Data Input to Each Flip-Flop
These flip-flops transfer information from D inputs to Q outputs on the positive-going edge of the clock pulse. Clock triggering is voltage-based and not time-based. D input has no effect on output when clock is high or low. Responds to clock frequencies from 0 to 30MHz, with a maximum of 40MHz. Power dissipation is 39mW per flip-flop for the 273 and 10mW for the LS273.
