2 Channel 12V Solid State Relay Module
A versatile solid-state relay module for controlling high-voltage AC loads
- Part Number: G3MB-202P
- Power supply: 3-24VDC/160mA
- Switching Voltage (VAC): 240@2A
- Isolation: Phototriac
- Zero Cross: Yes
- Length (mm): 105
- Width (mm): 57
- Height (mm): 24
- Weight (gm): 88
Top Features:
- 2-channel 2 AMP Solid State Relay board
- Control 8 loads of up to 2 amps each at 240 VAC
- Assembled and electrically tested
- Led indicator for each relay
A solid-state relay (SSR) functions like a mechanical relay but uses infrared light for contact, providing noise-free operation and a longer lifespan. When the input logic voltage is applied, the relay switches the connectivity between NC and COM, turning on or off the connected load.
Input Parts:
- DC+: connected to VCC (Supply power according to relay voltage)
- DC-: connected to GND
- IN1: CH1 Signal triggering the end of 1-channel relay module (active at the Low level)
- IN2: CH2 Signal triggering the end of 2-channel relay module (active at the Low level)
Use this module to control various appliances and equipment with a large current directly from a Microcontroller.
Package Includes: 1 x 8 Channel 24V Relay Module Solid State High-Level SSR DC Control 250V 2A with Resistive Fuse
* Images are for illustration only; actual product may vary.
