Waveshare Motor Control Board
Control Board with Dual H-Bridge Driver L293D for Easy Motor Control
- Onboard dual H-bridge driver: L293D
- Output current: 600mA (peak 1.2A) per single bridge
-
Features:
- Drives 2 DC motors or 1 stepping motor
- ESD protection
The Waveshare Motor Control Board is equipped with an onboard dual H-bridge driver L293D, allowing for easy motor control using Arduino or other development platforms. This driver board can drive 2 DC motors or 1 stepping motor simultaneously.
For motor rotation control, connect M1A/M1B and M2A/M2B to MCU digital IO. The board features a ground (GND) and requires a 5V power supply (VCC). The motor control options include:
- M1A/M2A and M1B/M2B: Counterclockwise/Clockwise
- M1A/M2A: 0, M1B/M2B: 1: Clockwise/Counterclockwise
- M1A/M2A and M1B/M2B: 1: Stop
- M1A/M2A and M1B/M2B: 0: Stop
Images are for illustration only; actual product may vary.
