URF4805QB-100WR3 Mornsun 48V to 5V DC-DC Converter
Isolated 100W DC-DC converter with 4:1 input voltage and 2250VDC isolation
- Input Voltage Range: 18-75V
- Nominal Voltage: 48V
- Output Voltage: 5V
- Output Current: 20A
- Wattage: 100W
- Isolation: 2.25kVDC
- Package: Five-sided metal shielded
Features:
- Ultra-wide 4:1 input voltage range
- High efficiency up to 94%
- I/O isolation test voltage: 2250VDC
- Operating ambient temperature range: -40°C to +85°C
URF4805QB-100WR3 series are isolated 100W DC-DC products with 4:1 input voltage. They feature efficiency up to 94%, 2250VDC input to output isolation, operating temperature of -40°C to +85°C, input under-voltage, output over-voltage, over-current, short circuit, over-temperature protection. EN62368 approved and they are widely used in applications such as battery powered systems, industrial controls, electricity, instrumentation, railway, communication, and intelligent robotics.
Industry standard ¼-Brick package and pin-out. The package includes 1 x URF4805QB-100WR3 Mornsun 48V to 5V DC-DC Converter 100W Power Supply Module - Five Sided Metal Shielded Package.
*Images are for illustration only; actual product may vary.
