UC3706 Family High-Speed Schottky Output Drivers
Interface between low-level control functions and high-power switching devices
- Features:
- Dual, 1.5A Totem Pole Outputs
- 40nsec Rise and Fall into 1000pF
- Parallel or Push-Pull Operation
- Single-Ended to Push-Pull Conversion
- Specs:
- Input: Single-ended, low-current digital input of either polarity
- Output: 1.5A each (totem pole)
- Optional Output: 3.0A parallel operation
- Protection: Pulse-by-pulse current limiting, automatic deadband control, thermal shutdown
- Temperature Range: 0°C to 70°C (plastic DIP), -55°C to +125°C (hermetically sealed cerdip)
- Packages: 16-Pin DIP, 20-Pin Q and L surface mount
The UC3706 output drivers are designed to efficiently handle the interface between low-level control functions and high-power switching devices. They accept single-ended, low-current digital inputs and activate high-current totem pole outputs with impressive capabilities. The devices also feature protection functions for safe operation.
These output drivers come in different package options to suit various operational requirements. Whether in a plastic "bat-wing" DIP or a hermetically sealed cerdip, the UC3706 devices deliver reliable performance over different temperature ranges.
