TC4420 6A Single-Output MOSFET Driver
High-performance, latch-up protected MOSFET driver with fast propagational delay time.
- Supply Voltage: +20V
- Input Voltage: -5V to VDD + 0.3V
- Input Current (VIN > VDD): 50 mA
- Package: 5-Pin TO-220 (With Heatsink)
- Package Power Dissipation: 12.5W
- Thermal Impedances (To Case): 10°C/W
Top Features:
- Latch-Up Protected: Withstands >1.5A Reverse Output Current
- High Peak Output Current: 6A
- Wide Input Supply Voltage Range: 4.5V to 18V
- Low Output Impedance: 2.5?
The TC4420 is a 6A (peak), single-output MOSFET driver with a non-inverting design. Fabricated in CMOS, it offers lower power consumption and superior efficiency compared to bipolar drivers. The device features TTL/CMOS compatible inputs that can tolerate voltage swings from VDD + 0.3V to -5V without any risk of damage.
One key advantage of the TC4420 is its rail-to-rail output swing, ensuring optimal drive voltage margin, particularly during power-up and power-down sequences. With a propagational delay time of just 55 ns (typ.) and rise/fall times of 25 ns (typ.) into 2500 pF, it offers fast and efficient operation within the usable power supply range.
Notably, the TC4420 boasts virtually latch-up proof capabilities, eliminating the need for multiple discrete components. This not only saves PCB space but also enhances overall system reliability. The device comes in space-saving 8-pin SOIC and 8-pin 6x5 DFN packages.
Specifications:
- Supply Voltage: +20V
- Input Voltage: -5V to VDD + 0.3V
- Input Current (VIN > VDD): 50 mA
- Package: 5-Pin TO-220 (With Heatsink)
- Package Power Dissipation: 12.5W
- Thermal Impedances (To Case): 10°C/W
