T-motor CubeMars AK10-9 V2.0 100KV Brushless DC Actuator Robot Joint Motor
Highly integrated & high torque motor with built-in reducer and controller
- Max Speed at Rated Torque(rpm): 222/445 (Output)
- Kt(Nm/A): 0.095
- Kv(RPM/V): 100
- Ke(virpm): 0.01
- Km(Nm/Vw): 0.3
- Number of Pole-Pair: 21
- Resistance Phase to Phase(m?): 905
- Inductance Phase to Phase(?H): 33110
- Op(mm): 098
- Max torque weight ratio(Nm/kg): 65
Top Features:
- Easy configuration with RUBIK Link
- 12Bit Encoder & UART/CAN Interface
- Applied to Exoskeleton, Quadruped Robotic Dog
- Large Torque for Robotic Applications
Packages Includes: 1 x T Motor AK10-9/V1.1
* Images are for illustration only; actual product may vary.
