24V Enclosed Type Power Supply - G3 Series
Reliable 15W power supply with standard features and 3 years warranty
- Output Voltage: 24V
- Type: Enclosed Type
- Approx. Wattage: 15W
- Features: Standard
- Series: G3 (Reliable)
- Mechanical Form: Enclosed
- Warranty: 3 Years Warranty
- IP Level: Non-Waterproof
- Input Voltage: 100-240V auto-select
Top Features:
- All capacitors are 105°C long life electrolytic
- Short circuit, overload, over voltage, and over temp protections
- Meets EMS EN50082-2/EN61000-6-2 standards
- High efficiency and reliability with LED power indicator
Specifications:
- AC Input Voltage Range: 85~264VAC, 120~370VDC
- DC Adjustment Range: ±10%
- Overload Protection: >105%, hiccup mode
- Over Voltage Protection: 115%~135%, shut off
- Withstand Voltage: I/P - O/P: 3kVAC, I/P - FG: 1.5kVAC, O/P - FG: 0.5kVAC
- Working Temperature: -20~+70°C
- Vibration: 10~500Hz, 5G 10min.
- Safety Standards: UL60950-1, TUV EN60950-1 approved
Related Documents:
- RS-15 Datasheet
- RS-15-24 Test Report
- CE Certificate (RS-15)
- UL Certificate (RS-15)
- CB Certificate (RS-15)
- TUV Certificate (RS-15)
- EMC Certificate (RS-15)
* Images are for illustration only; actual product may vary.
