PE52627NL Through Hole Toroidal Inductors
High-quality toroidal inductor for various applications
- Inductance: 470 uH
- Tolerance: 10%
- Maximum DC Current: 500 mA
- Maximum DC Resistance: 1.3 Ohms
- Operating Temperature: 20°C to +80°C
- Self Resonant Frequency: 1.8 MHz
- Termination: Standard
- Mounting Style: PCB Mount
- Core Material: Ferrite
Top Features:
- High inductance of 470 uH
- Wide operating temperature range
- Low maximum DC resistance of 1.3 Ohms
- Standard termination for easy installation
Inductors, like capacitors, can hold a charge or power within them after a certain time and can maintain that power source even when an outside supply is removed. An inductor stores energy in the form of a magnet. The defining feature of an inductor is a resistance to change in current. A radial inductor has a similar design to radial electrolytic capacitors whereby the inductor stands upright on the PCB and has two legs protruding from the bottom.
Applications include power supplies, DC/DC converters, and general use.
* Images are for illustration only; actual product may vary.
