DC 24V KK-P20/15 3KG Lifting Solenoid Electromagnet
An efficient and reliable electromagnet for high-power magnetic applications.
- Model: 24V KK-P20/15
- Holding/ Suction Force (KG): 3
- Operating Voltage (VDC): 24
- Max. Operating Current (mA): 0.17
- Power Consumption (Watt): 2
- Operating Temperature Range (C): -20 to 120
- Cable Length (cm): 30
- Body Material: Mild Steel
- Dimensions (LxWxH) in mm: 20 x 15 (Dia. x Length)
- Weight (gm): 35
Features:
- High-power magnetic field with low energy consumption.
- Minimized residual magnetic force.
- Lightweight and compact design.
- Long life with high durability.
This DC 24V KK-P20/15 3KG Lifting Solenoid Electromagnet is designed with an iron core and a coil to attract magnetic substances when an electric current is applied. It offers high power and reliability, with a unique feature to release residual magnetism after de-energization.
Working Principle: An electromagnet energizes when connected to a DC voltage, creating a magnetic field. The polarity and strength of the magnetic field depend on the current flow direction and magnitude.
Precaution: Ensure proper conditions for maximum suction, including magnetic permeability, power supply, object cleanliness, size, and proximity to the electromagnet.
Package Includes: 1 x DC 24V KK-P20/15 3KG Lifting Solenoid Electromagnet, 1 x M4 Bolt with Washer
* Images are for illustration only; actual product may vary.
